Elevators Quadruplex 1600 Kg e 2000 Kg

QUADRUPLEX are the specific lifts for vineyards, greenhouse cultivation, fruit growing and horticulture.

The profiles are hot-rolled pressed steel in the shape of “”U”” and “”H”” and they slide on special bearings with contrast washers, the lifting cylinders are double-acting and lateral, the four lifting chains are FLEYER.

Available in two versions with a maximum load capacity of 1,600 and 2,000 kg and lifting heights of up to 6,000 mm, QUADRUPLEX is extremely easy to use!

Minimum space requirements and free lift are the necessary features for maximum performance. Attached to the tractor, the footprint is reduced to a minimum to facilitate handling and storage in green areas, lawns, gardens, warehouses and small greenhouses.

QUADRUPLEX and all Tecnoagri forklifts allow you to customise your experience! Choose from a wide range of fittings and accessories to add value to your business!

Quadruplex elevator in evidence 2

Load capacity in motion

1.600 / 2.000 Kg.

Quadruplex elevator in evidence 1

Max. lifting height

6.000 mm

Quadruplex elevator in evidence 3

Profiles

4 profiles: U and H forms, sliding on bearings

Tecnoagri Elevator Movement

Customise your user experience.

All Tecnoagri forklifts are available with 1 to 4 hydraulic movements: lifting, tilting, fork translation and axle tightening.

Quadruplex elevator feature 1

Two double-acting side cylinders

The double-acting cylinder improves control over load lifting and lowering movements.
The double-acting cylinder improves control over the raising and lowering of the load.

Quadruplex elevator feature 2

Chains and pipes

The hydraulic hoses and four high-strength Fleyer lifting chains are specifically positioned for better visibility.
Hydraulic hoses and four high-strength Fleyer lifting chains are specifically positioned for better visibility

Quadruplex elevator feature 3

Minimum space required on the tractor

Thanks to the four profiles, the Quadruplex models are specifically designed to work in crops with limited height, under the pergola, in greenhouses and in orchards.
Thanks to the four profiles, the Quadruplex models are specifically designed to work in crops with limited height, under the pergola, in greenhouses and in orchards.

Quadruplex elevator feature 3

Free lift 200 mm.

The free lift allows the forks to rise 200 mm before the masts rise. A specific technology for working in crops with limited access.

Strings with extra-elevation

The special double cylinder technology enables the stabilisation of high load up to 2,800 mm.

Solid steel forks

To improve usage performance

Accessories

Box Comandi Joystick
Box Joystick
Cilindri Brandeggio
Cilindri Brandeggio
Manipolatore Cobra
Cobra manipulator
Coppia Forche Acciaio
Coppia Forche Acciaio
Coppia Forche FEM
Coppia Forche FEM
